Diameter

Weight

1470

1570

1670

1770

1870

mm

kg/100m

Minimum Breaking Load of Rope (KN)

4

6.2

7.7

8.2

8.8

9.3

9.8

5

9.8

12.1

12.9

13.7

14.5

15.3

6

14

17.4

18.5

19.7

20.9

22.1

7

19.1

23.6

25.2

26.8

28.4

30.1

8

25

30.9

33

35.1

37.2

39.3

9

31.6

39.1

41.7

44.4

47

49.7

10

39

48.2

51.5

54.8

58.1

61.3

11

47.2

58.3

62.3

66.3

70.2

74.2

12

56.2

69.4

74.2

78.9

83.6

88.3

13

65.9

81.5

87

92.6

98.1

104

14

76.4

94.5

107

107

114

120

16

99.8

123

132

140

149

157

18

126

156

167

177

188

199

20

156

193

206

219

232

245

22

189

233

249

265

281

297

24

225

278

297

316

334

353

26

264

326

348

370

392

415

28

306

378

404

429

455

481

30

351

434

463

493

523

552

32

399

494

527

561

594

628
