WIRE DIA.

IN LENGTH

IN W.

OUT W.

W.L.L.

M.B.S.

LENGTH/11LINK

WT./100M

(MM)

(+-MM)

(MM)

(+MM)

(-MM)

(MM)

(MM)

(KN)

(KN)

(MM)

(+MM)

(-MM)

(KG)

3

0.20

16

0.2

0.2

4.2

11

1.12

2.8

176

1.4

0.7

16

4

0.20

16

0.3

0.2

5

13.7

2

8

176

2.1

1.1

32

5

0.20

18.5

0.4

0.2

6

17

3.2

12.5

203.5

2.4

1.2

50

6

0.20

18.5

0.4

0.2

7.2

20.2

4

16

203.5

2.4

1.2

80

7

0.30

22

0.4

0.2

8.4

23.8

6.3

25

242

3.0

1.4

110

8

0.30

24

0.4

0.2

9.6

27.2

8

32

264

3.2

1.5

140

9

0.40

27

0.5

0.3

10.8

30.6

10

40

297

3.6

1.8

180

10

0.40

28

0.5

0.3

12

34

12.5

50

308

3.7

1.9

220

11

0.40

31

0.5

0.3

13.2

37.4

16

63

341

4.0

2.0

270

13

0.50

36

0.6

0.3

15.6

44.2

20

80

396

4.6

2.4

380

14

0.60

41

0.7

0.4

16.8

47.6

25

100

451

5.4

2.7

440

16

0.60

45

0.8

0.4

19.2

54.4

32

125

495

6.0

3.0

570

18

0.90

50

0.8

0.4

21.6

61.2

40

160

550

6.6

3.3

730

20

1.00

56

1.0

0.5

24

68

50

200

616

7.4

3.7

900

23

1.20

64

1.1

0.5

27.6

78.2

63

252

704

8.4

4.2

1200

26

1.30

73

1.2

0.6

31.2

88.4

75

300

803

9.6

4.8

1500
